Factory Water Treatment Filters Steam Boiler Industrial High Pure Water Reverse Osmosis System

Pure water / high purity water treatment system is a kind of device to achieve the purpose of water purifying through various water treatment processes and water quality monitoring system. As per the users’ different requirements of the purity of the water, we combine and permute the pretreatment, reverse osmosis and mixed bed ion exchange (or EDI electric desalting unit) to make a set of tailored pure water treatment equipment, moreover, all the water tanks in the system are equipped with liquid level control system, and the pumps are equipped with pressure protection device, on-line water quality detection and control instrument and PLC programmable controller are applied for the whole system to make the equipment running with no labor on duty.

Parameters:

lRO membrane:Hydranautics,Dow or GE

lMembrane Vessel: FRP or stainless steel material from ROPV and First line

lHigh pressure pump:Grundfos or CNP

lFrame: carbon steel paint epoxy zinc-rich bottom, intermediate paint, polyurethane finish or stainless steel

lPipeline: High-pressure pipeline material is stainless steel or high pressure hose, low pressure pipeline material is UPVC

lElectrical: PLC from Siemens or ABB, electrical components from Schneider

Performance characteristics:

lMature and advanced technology, high automation, can achieve the machine's automatic operation

lEquipment is operating continuously, product water quality is stable

lReverse osmosis water equipment combination type can be achieved: bracket type, skid type, truck type, container type, etc.

Applications:

Direct Flow High pressure Steam boiler (steam injection boiler) for Oilfield heavy oil recovery

Brewery

Power plant

Pharmaceutical water

Public works

Processing:

Raw water tank ð Raw water pumpð Quartz sand filter ðOne stage security filter ðUF systemð UF treated water tank ðRO high pressure pump ð RO water tank ð Two stage high pressure pumpð Two stage RO unit ð RO water tankð Ion exchanger booster pump ð Ion exchanger ðDegasser unit ð Water supply pump

Packaging Detail: plywood case exporting standard

Delivery Detail: 15~90 days

1. Water quality test and analysis of raw water

2. 100% factory tested before shipment

3. services of 24h after sale

4. supply of chemicals,filter elements,membranes and other consumable spare parts

5. one year equipment warranty

Enterprise Profile:

Yantai Jietong Water Treatment Technology Co., Ltd. is specialized in industrial water treatment, seawater desalination, and sewage treatment, is a new high tech enterprise professional for water treatment plant consulting, research, development, production and sales, we have obtained a number of inventions and patents, and achieved the accreditation of quality management system standard GB T19001 2008 , environmental management system standard GB T24001 2004 and occupational health and safety management system standard GB T28001 2011.

We supplied as following:

1. Industrial water treatment machines: softener, pure water machine, high pure water machine, chemical dosing system for cycling water;

2. Seawater desalination plant, seawater multipurpose, seawater electrolysis system for corrosion prevention, electrolysis plant producing chlorine gas and sodium hypochlorite solution;

3. Industrial and sanitary sewage treatment.

Projects:

Certificate:

Contact:

Yantai JieTong Water Treatment Technology Co., LTD

Address: West of Hongqi Road, Zhichu Industrial Park
Whatsapp:+86-13791279160
Fax: +86-535-6808891

1. Business type?
manufacturer and trading company in Yantai
2. Delivery time?
30-90 days after receving deposit.

3. Quality control?

We have a strict quality control system, professional QC team with ISO9001.
